Sontay Differential Pressure Switch

The PA-DPS-8x range of air differential pressure switches are suitable for low differential pressure switching applications, and are ideal for providing indication of fan status or ‘filter dirty’ conditions in air, non-combustible, non-aggressive gases in air conditioning and ventilating installations. The switching knob is mounted under the cover to avoid tampering.

Specification:
● Measurement ranges: 50 to 500Pa
● Differential: 20Pa
● Maximum Pressure: 5000Pa
● Pressure Connections: 6mm ID push-on tubing
● Electrical Rating: 1.5A (0.4) @ 250Vac
● Approvals Switch according to VDE0630 UG1652
● Connections: Via 6.3mm crimp-type sockets
● Cable entry: PG11
● Material: Plastic Moulding
● Dimension: 130 x 130 x 99mm
● Ambient:
● Temp: -20 to +85̊C̊C
● RH: 0 to 95% non-condensing
● Protection: IP54
● Country of Origin: Germany
