Sertus Roof Single Leaf Smoke Vent -RSL-R

Roof Single Leaf – Residential (RSL-R) units are principally designed for smoke and heat ventilation in protected stairwells and corridors within residential apartments, hotels, shops, and offices. Roof Single Leaf – Residential (RSL-R) are available as square or rectangular.

They may be glazed in polycarbonate rooflight in single, double, triple or quad skin or with aluminium insulated solid cover. The polycarbonate rooflights are available as clear, opal or heat reflect. The aluminium insulated covers are available as mill finish or powder coated to any RAL colour.

The electric actuator is 24 volt DC and opens the units to 160° within 60 seconds. A wide range of upstands are available to accommodate roof insulation or an adaptor may be installed to builder’s upstands. Roof Single Leaf – Residential (RSL-R) may also be used for roof access and to provide natural ventilation.

• Fully certified to BS EN12101-2
• Compliant with Building Regulations Approved Document B and L
• Opens to 160 degrees within 60 seconds
• May incorporate roof access
• Provides natural comfort ventilation–EN 1873 Class B
• Available as square or rectangular
• May be glazed or solid insulated lid
• Available with PVC upstand or direct to builder's upstand
• Fire rated to EN13501-1
• Fire rating B-s3, d0 to EN13501-1
